Penumatic Universal Sampler
HY-03Q
The Fabric Sample Cutting Machine is a specialized instrument driven by a safe, clean high-pressure air source, paired with various steel die cutters.
Quantity:
Product Overview
The Fabric Sample Cutting Machine is a specialized instrument driven by a safe, clean high-pressure air source, paired with various steel die cutters. It is designed to cut fabric samples for different tests, solving the time-consuming and labor-intensive problem of sample cutting in daily laboratory work—effectively ensuring the smooth progress of various tests and the reliability of samples.
The Fabric Sample Cutting Machine is a specialized instrument driven by a safe, clean high-pressure air source, paired with various steel die cutters. It is designed to cut fabric samples for different tests, solving the time-consuming and labor-intensive problem of sample cutting in daily laboratory work—effectively ensuring the smooth progress of various tests and the reliability of samples.
Application Scope
Suitable for cutting samples for various tests (formaldehyde, PH, gram weight matching, abrasion resistance, pilling, strength, washing, stiffness, static electricity, water absorption, wrinkles, etc.) via different steel die cutters;
Used to cut circular or irregular samples of various fabrics (wool, cotton, chemical fiber, knitting, etc.).
Suitable for cutting samples for various tests (formaldehyde, PH, gram weight matching, abrasion resistance, pilling, strength, washing, stiffness, static electricity, water absorption, wrinkles, etc.) via different steel die cutters;
Used to cut circular or irregular samples of various fabrics (wool, cotton, chemical fiber, knitting, etc.).
Instrument Features
1.Adopts safe and clean high-pressure air source power, paired with various steel die cutters;
2.Solves the time, labor and effort costs of sample cutting in daily laboratory work;
3.Ensures the smooth progress of various tests and the perfection/reliability of samples.
1.Adopts safe and clean high-pressure air source power, paired with various steel die cutters;
2.Solves the time, labor and effort costs of sample cutting in daily laboratory work;
3.Ensures the smooth progress of various tests and the perfection/reliability of samples.
Technical Parameters
Parameter Specification
1.Sampling Types 5mm×5mm (with spring), 40mm×100mm, 60mm×350mm, 60mm×250mm, 50mm×200mm, 100mm×220mm, ∅112.8mm, ∅38mm, ∅140mm, ∅90mm, etc.; die cutter sizes can be customized (within 220×300mm) as needed
2.Maximum Output Force ≥3T
3.Working Principle Gas-pressurized die cutting
4.Sampling Thickness ≤15mm
5.Dimensions (L×W×H) 400×600×800mm
6.Weight 160Kg
7.Optional Die Cutters
8.Note: Besides the following list, other types can be customized (3 standard samples optional).
Parameter Specification
1.Sampling Types 5mm×5mm (with spring), 40mm×100mm, 60mm×350mm, 60mm×250mm, 50mm×200mm, 100mm×220mm, ∅112.8mm, ∅38mm, ∅140mm, ∅90mm, etc.; die cutter sizes can be customized (within 220×300mm) as needed
2.Maximum Output Force ≥3T
3.Working Principle Gas-pressurized die cutting
4.Sampling Thickness ≤15mm
5.Dimensions (L×W×H) 400×600×800mm
6.Weight 160Kg
7.Optional Die Cutters
8.Note: Besides the following list, other types can be customized (3 standard samples optional).
